KEXINT FTTH Spiral Armored Optical Cable 2 Cores 5.0mm With Corrugated Tube

Name: KEXINT FTTH Spiral Armored Optical Cable 2 Cores 50mm With Corrugated Tube
Brand: KEXINT
Price: 1.42 USD

China KEXINT FTTH Spiral Armored Optical Cable 2 Cores 5.0mm With Corrugated Tube factory

Brand Name : KEXINT

Model Number : 2c armored 5.0 LC

Certification : CE/ROHS/ISO9001

Place of Origin : Guangdong

MOQ : 50+pcs

Price : 1.42+$+piece

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram, MoneyGram

Supply Ability : 1000+PCS+Day

Delivery Time : 8

Packaging Details : box

Cable diameter : 5.0mm

Jacket Color : Black....customized

Jacket Material : PVC / TPU/ LSZH / OFNR

Fiber Count : 2 core DX

Fiber type : G652D/G657A1/G657A2

wavelength : 1310 1550

Operating Temperature (°C) : -40℃~85℃

Contact Now

Waterproof fiber optic cable assemblies are installation-friendly for fixed or mobile applications and transmit reliably data over long distances under severe environmental conditions.

 Application :
Local Area Network (LAN)

Data communication network

Telecommunication optical transmission network

Optical access network(OAN)

Active device termination

Fiber optics data transmission

Test Equipment and CATV

Gigabit Ethernet

Features :

1; Comply with IEC, Telcordia-GR-326-Core standards;

2; Different size & color boot option;

3; Low insertion loss; High return loss;

4; 100% interferometer measurement;

KEXINT FTTH Spiral Armored Optical Cable 2 Cores 5.0mm With Corrugated Tube

parameter	SM		MM
outer diameter	5.0MM		5.0MM
standard color	black		black
Weight	about 35kg/km		about 35kg/km
Operating Temperature	-20℃～+70℃
Pull	Short term	1200N	Short term	1200N
	Long-term	600N	Long-term	600N
Compressive strength	≥3000N/100MM		≥3000N/100MM
attenuation	1310nm	0.4dB/km	850nm	3.0dB/km
	1550nm	0.3dB/km	1300nm	1.0dB/km
Minimum bending radius	≥20D		≥20D


Our advantages:

Good reply: Your inquiry related to our products or price will be replied within 24 hours.

OEM&ODM: We can help you to design or put your logo and company name into products.

Remote Technical support&Full Technical Document

Warranty: 1 year warranty( While the warranty is not responsible for those broken by violence or updated with other brands.)

English software, English Indicator

Professional, Very competitive price

Large Stock, Fast Delivery

Quality Assurance
